ABB TED134010 Ge Qline Molded Case Circuit Breaker
Part Number # TED134010
SKU # 2437995
$1544.00 / Each
ABB TED134010 Key Features
Brand: ABB
Part Number # TED134010
SKU #2437995
Actuator Type: Toggle Handle
Amperage Rating: 10 A
Dimensions: 4-1/8 in W x 3-3/8 in D x 6-5/16 in H
Frame: E150
Frequency Rating: 50/60 Hz
Interrupt Rating: 18 kA
Number of Poles: 3
Phase: 3
Temperature Rating (Degrees F): 10 to 50 deg C
Trip Type: Non-Interchangeable/Thermal Magnetic/Long Instantaneous
Type: Type TED Core E Mid Tier
Voltage Rating: 480 VAC
Connection type: Load Lug
Material: Plastic
Mounting type: Bolted-On
Manufacturer Name: ABB
UNSPSC: 39121601
UPC: 00783164069419
$1544.00 / Each
ABB TED134010 Ge Qline Molded Case Circuit Breaker
Additional Description: ABB -TED134010 (N) 3 POLE 480VAC 10A BREAKER NON-CANCELABLE, NON-RETURNABLE
Catalog Description: The E150 product line consists of Thermal Magnetic Circuit Breakers, Magnetic Circuit Breakers, and Molded-Case Switches rated up to 150 Amps and 600 Volts AC. Catalog numbers include the complete breaker or switch. The WL catalog number suffix indicates that the devices come with Cu/Al line and load lugs. All TEB, TED, THED breakers suitable for reverse feed. 60/75 C rating through 100 amperes, 75 C rating above 100 amperes. 3 POLE 480VAC 10A BREAKER
TED134010 Application
Industrial, Switchboards, Motor Control Centers, Lighting, Power, Customized Control Panelboards, Electrical Distribution and Control ApplicationsTED134010 Item Features
- Molded case is molded from high mechanical and high dielectric strength engineered plastic
- Trip indication is shown by handle position midway between ON and OFF, to reset the trip mechanism, move the handle to extreme OFF, then to ON position
- Quick make, quick break, trip free mechanism minimizes arcing during breaker operation, contacts cannot be teased into position
- Trip free mechanism is independent of manual handle control, the breaker trips under short circuit or overload, even though the operating handle is held in ON position
- VERIFIER "Twist-to-Trip" and Push-to-Trip mechanically simulates over current tripping through actuation of linkages not operated by the ON/OFF handle
- Common trip bar assures instant disconnect of all conductors when an overload or short circuit occurs on any one conductor in the circuit or an accessory trip device operates
- Silver alloy contacts combine the conductive properties of silver with other elements for clean, positive electrical contacting, pitting and burning are minimized for longer contact life
- Arc chutes of heat absorbing, insulating material and metal grid plates quickly extinguish arcs
- UL Listed lugs for copper or aluminum cable, at full frame rating, easy access and simple, straight-in wiring
- Suitable for reverse feed applications
- 10 kA at 125 VDC, 10 kA at 250 VDC, 10 kA at 500 VDC, 14 kA at 600 VAC, 18 kA at 120 VAC, 18 kA at 120/240 VAC, 18 kA at 240 VAC, 18 kA at 277 VAC, 18 kA at 480 VAC interrupt rating
TED134010 Standards
CSA File No. LR57114SKU #2437995Part Number #TED134010UNSPSC39121601UPC00783164069419
