Brand: Bussmann
NON-80
Bussmann NON-80 General Purpose Fuse
Part Number # NON-80
SKU # 2244597
$430.55 / 5Each
Typical price:$875.55 / Each
Bussmann NON-80 Key Features
| Brand: | Bussmann |
|---|---|
| Part Number # : | NON-80 |
| SKU #: | 2244597 |
| Amperage Rating: | 80, 80 A |
| Body Type: | Cartridge Blade |
| Class: | H |
| Indicating/Non-Indicating: | Non-Indicating |
| Interrupt Rating: | 10, 10/50 kA |
| Rejection/Non-Rejection: | Non-Rejection |
| Series: | NON |
| Terminal Type: | Blade |
| Type: | General Purpose Non-Current Limiting, Non-Current Limiting One Time |
| Country of origin: | MX |
| Material: | Melamine |
| Mounting type: | Holder |
| Manufacturer Name: | Eaton |
| UNSPSC: | 39121605 |
| UPC: | 00051712101660 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
$430.55 / 5Each
Typical price:$875.55 / Each
Quantity:
- Bussmann One-Time Fuse, General Purpose Non-Current Limiting, Series: NON, Indicating/Non-Indicating: Non-Indicating, Rejection/Non-Rejection: Non-Rejection, 80 A, 250 V AC/125 V DC, 10/50 kA Interrupt, Class: H, Blade Terminal, Holder Mount, Cartridge Blade Body Type, Single Element, Melamine, 1.06 in Dia x 5.88 in L Body Size
NON-80 Application
For light duty circuit locations, safety and security systemsNON-80 Item Features
- Original fuse providing circuit protection
- Protect lighting, heating and other circuits not subject to temporary surges and where available short circuit currents are relatively low
- Do not have any appreciable degree of time delay and thus should not be specified in circuits where large transients or motor overloads occur
- Use Bussmann advanced protection Fusetron FRN-R or ultimate protection Low-Peak LPN-RK dual element, time delay fuses
- For general purpose circuits, size at amp rating of circuit
- For motor circuits, size at 300% to 400% according to the NEC motor ampacity tables 430.247 to 430.250 per 430.6(A)(1)
- https://www.youtube.com/watch?v=YMvqUyoETXk
NON-80 Standards
CE Certified|CSA 1421-01|CSA File No. 53787|UL 248-6|UL File No. E4273|UL Guide JDDZSKU #2244597Part Number #NON-80UNSPSC39121605UPC00051712101660
