Brand: Bussmann
NOS-150
Bussmann NOS-150 General Purpose Fuse
Part Number # NOS-150
SKU # 2198123
$297.17 / Each
Typical price:$604.30 / Each
Bussmann NOS-150 Key Features
| Brand: | Bussmann |
|---|---|
| Part Number # : | NOS-150 |
| SKU #: | 2198123 |
| Amperage Rating: | 150, 150 A |
| Body Type: | Cartridge, Cartridge Blade |
| Class: | H |
| Indicating/Non-Indicating: | Non-Indicating |
| Interrupt Rating: | 10, 10 kAIC |
| Rejection/Non-Rejection: | Non-Rejection, Rejection |
| Series: | NOS |
| Terminal Type: | Blade, Blade End |
| Type: | Non-Current Limiting One Time, One-Time Non-Current Limiting |
| Country of origin: | MX |
| Material: | Melamine |
| Mounting type: | Holder |
| Manufacturer Name: | Eaton |
| UNSPSC: | 39121605 |
| UPC: | 00051712311502 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
$297.17 / Each
Typical price:$604.30 / Each
Quantity:
- Bussmann Fuse, One-Time Non-Current Limiting, Series: NOS, Indicating/Non-Indicating: Non-Indicating, Rejection/Non-Rejection: Rejection, 150 A, 600 V AC, 10 kAIC Interrupt, Class: H, Blade End Terminal, Holder Mount, Cartridge Body Type, Single Element, Melamine, 2.59 in Dia x 11.63 in L Body Size
NOS-150 Application
Industrial Facilities and Factory Facility, Safety and Security Systems, Light Duty Circuit Locations ApplicationsNOS-150 Item Features
- Original fuse providing circuit protection
- Protect lighting, heating and other circuits not subject to temporary surges and where available short circuit currents are relatively low
- Do not have any appreciable degree of time delay and thus should not be specified in circuits where large transients or motor overloads occur
- Use Bussmann advanced protection Fusetron LPS-R or ultimate protection Low-Peak LPS-RK dual element, time delay fuses
- For general purpose circuits, size at amp rating of circuit
- For motor circuits, size at 300% to 400% according to the NEC motor ampacity tables 430.247/430.250/ 430.6(A)(1)
- One-time fuse
- https://www.youtube.com/watch?v=YMvqUyoETXk
NOS-150 Standards
CE Certified|CSA Class 1421-01 File No. 53787|UL 248-6 Guide No. JDDZ File No. E4273SKU #2198123Part Number #NOS-150UNSPSC39121605UPC00051712311502
