Part Number # NOS-450
SKU # 2252576
Image provided may only be a representation of
final product and may include optional equipment
NOS-450
Bussmann NOS-450 General Purpose Fuse
Part Number # NOS-450
SKU # 2252576
Bussmann NOS-450 Key Features
| Brand: | Bussmann |
|---|---|
| Part Number # : | NOS-450 |
| SKU #: | 2252576 |
| Amperage Rating: | 450, 450 A |
| Body Type: | Cartridge, Cartridge Blade |
| Class: | H/K5, K5 |
| Indicating/Non-Indicating: | Non-Indicating |
| Interrupt Rating: | 10, 10 kAIC |
| Rejection/Non-Rejection: | Rejection |
| Series: | NOS |
| Terminal Type: | Blade, Blade End |
| Type: | Non-Current Limiting One Time, One-Time Non-Current Limiting |
| Country of origin: | MX |
| Mounting type: | Holder |
| Manufacturer Name: | Eaton |
| UNSPSC: | 39121605 |
| UPC: | 00051712314503 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
Bussmann NOS-450 General Purpose Fuse
Brand: Bussmann
Part Number: NOS-450
Bussmann Fuse, One-Time Non-Current Limiting, Series: NOS, Indicating/Non-Indicating: Non-Indicating, Rejection/Non-Rejection: Rejection, 450 A, 600 VAC, 10 kAIC Interrupt, Class: K5, Blade End Terminal, Holder Mount, Cartridge Body Type, 3.13 in Dia x 13.38 in L Body Size
Additional Description: BUSS-NOS-450 (N) BUSS ONE TIME FUSE NON-CANCELABLE, NON-RETURNABLE
Catalog Description: Eaton Bussmann Series Class K5 fuse, NOS, general purpose, non-current-limiting fuses, 450 A, one-time fuse, interrupting rating of 10 kA at 600 Vac
NOS-450 Application
Industrial Facilities and Factory Facility, Safety and Security Systems, Light Duty Circuit Locations ApplicationsNOS-450 Item Features
- Original fuse providing circuit protection
- Protect lighting, heating and other circuits not subject to temporary surges and where available short circuit currents are relatively low
- Do not have any appreciable degree of time delay and thus should not be specified in circuits where large transients or motor overloads occur
- Use Bussmann advanced protection Fusetron LPS-R or ultimate protection Low-Peak LPS-RK dual element, time delay fuses
- For general purpose circuits, size at amp rating of circuit
- For motor circuits, size at 300% to 400% according to the NEC motor ampacity tables 430.247/430.250/ 430.6(A)(1)
- One-time fuse
- https://www.youtube.com/watch?v=YMvqUyoETXk
NOS-450 Standards
CE Certified|CSA Class 1421-01 File No. 53787|UL 248-6 Guide No. JDDZ File No. E4273SKU #2252576Part Number #NOS-450UNSPSC39121605UPC00051712314503
