QC75DTCB
Hammond Power Solutions QC75DTCB Buck Boost Transformer
Part Number # QC75DTCB
SKU # 2265088
$394.84 / Each
Typical price:$483.00 / Each
Hammond Power Solutions QC75DTCB Key Features
| Brand: | Hammond Power Solutions |
|---|---|
| Part Number # : | QC75DTCB |
| SKU #: | 2265088 |
| Dimensions: | 4-3/4 in L x 5 in W x 9-1/4 in H |
| Enclosure Type: | NEMA 3R |
| Frequency Rating: | 50/60, 50/60 Hz |
| Insulation: | 130, 130 deg C |
| Phase: | 1 |
| Primary Voltage: | 240 x 480, 240 x 480 VAC |
| Secondary Voltage: | 24 x 48, 24 x 48 VAC |
| Series: | Universal |
| Temperature Rating (Degrees F): | 30 to 40, 30 to 40 deg C |
| Type: | Dry Type Encapsulated Potted Low Voltage |
| Connection type: | Copper Tab/Wire Lead |
| Mounting type: | Wall |
| Manufacturer Name: | Hammond Power Solutions |
| UNSPSC: | 39121025 |
| UPC: | 00803423033897 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
$394.84 / Each
Typical price:$483.00 / Each
Quantity:
Hammond Power Solutions QC75DTCB Buck Boost Transformer
Brand: Hammond Power Solutions
Part Number: QC75DTCB
HPS Universal Buck Boost Transformer, Dry Type Encapsulated Potted Low Voltage, 240 x 480 VAC Primary, 24 x 48 VAC Secondary, 0.75 kVA Power, 50/60 Hz Frequency, 1 Phase, Copper Tab/Wire Lead Connection, Wall Mounting, 130 deg C Insulation, NEMA 3R Enclosure, 30 to 40 deg C, 4-3/4 in L x 5 in W x 9-1/4 in H Dimensions
Additional Description: HPS -QC75DTCB POTTED BUCK BOOST 1PH 750VA 240/480-24/48 CU
QC75DTCB Application
For correcting off-standard voltages and Indoor/outdoor applicationsQC75DTCB Item Features
- Encapsulated core and coils in a combination silica sand and resin compound
- Designed with a heavy duty NEMA 3R enclosure
- Encapsulated transformers can be used to buck and boost voltage in 1 and 3-phase applications where supply voltages are frequently above or below nominal
- These transformers can also be used in low voltage transformer application
QC75DTCB Standards
RoHS Compliant|UL Listed|CSA Certified|ANSI/ISA 12.12.10 E258346|Class 1 Div 2 Groups A/B/C/D|ABS No. 04-HS435190/1-PDASKU #2265088Part Number #QC75DTCBUNSPSC39121025UPC00803423033897
