- Smooth, rounded integral bushing in each hub protects conductor insulation
- Cast in mounting lugs
- Green ground screw
- Cover and gasket furnished with box as standard
- External threaded body provides additional wiring room
Specifications
Brand: Hubbell
Capacity: 25 cu-in
Cover Opening Size: 3-1/2 in
Dimensions: 3-1/2 in H x 4-1/2 in W x 11/16 in D
Finish: Powder Epoxy Painted
Series: GRUE
Size: 3/4 in
Country of origin: MX
Material: Copper Free Aluminum
Manufacturer Name: Hubbell
UNSPSC: 39121314
UPC: 00783936004556
Item FeaturesUsed in hazardous areas to protect conductors in threaded rigid conduit, act as pull and splice boxes, interconnect lengths of conduit, change conduit direction and provide access to conductors for maintenance and future system changes
Item Features
Item FeaturesUL File No. E10514|CSA File No. LR11716, Class I, Div 1, 2, Group B, C, D, Class I, Zone 1, 2, Group IIC, IIB, IIA, Class II, Div 1, 2, Group E, F, G, Class III, Div 1, 2
