Rittal 3210500 Heat Exchanger
Part Number # 3210500
SKU # 2267160
Rittal 3210500 Key Features
| Brand: | Rittal |
|---|---|
| Part Number # : | 3210500 |
| SKU #: | 2267160 |
| Air Flow Rate: | 479.7/544.4, 479.7/544.4 cfm |
| Ambient Temperature Rating: | 1 to 70, 1 to 70 deg C |
| Amperage Rating: | 0.44/0.5, 0.44/0.5 A |
| Capacity: | 13648, 13648 Btu |
| Dimensions: | 16 in H x 24 in W x 19 in D |
| Enclosure Type: | NEMA 12/IP55 |
| Frequency Rating: | 50/60, 50/60 Hz |
| Pressure Rating: | 1 to 10, 1 to 10 bar |
| Series: | SK Series |
| Type: | 1-Phase Air/Water |
| Mounting type: | Roof |
| Manufacturer Name: | Rittal |
| UNSPSC: | 40101802 |
| UPC: | 00639889375444 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
Rittal 3210500 Heat Exchanger
Brand: Rittal
Part Number: 3210500
Rittal Heat Exchanger, 1-Phase Air/Water, Series: SK Series, 230 VAC, 0.44/0.5 A, 100/120 W Power, 50/60 Hz Frequency, NEMA 12/IP55 Enclosure, 479.7/544.4 cfm, 13648 Btu Capacity, 1 to 70 deg C Ambient, 1 to 10 bar Pressure, Roof Mounting, Light Gray, 16 in H x 24 in W x 19 in D Dimensions
Additional Description: RTL -3210500 A-W HEX 13661BTU 230V 50-60HZ TYPE12 ROOFMTG, COMFORT CONTROL, RAL 7035, STEEL TYPE12 50/60HZ TYPE12 ROOFMTG, COMFORT CONTROL, RAL 7035, STEEL NON-CANCELABLE, NON-RETURNABLE
Catalog Description: SK Air/water heat exchanger, roof-mounted, 4 kW, 230 V, 1PH, 50/60 Hz, Water-carrying parts: copper/brass , WHD: 597 x 417 x 475 mm
3210500 Application
Climate Control Solutions Applications3210500 Includes
Plug-In Terminal Strip, Drilling Template, Sealing Mat, Assembly Components3210500 Item Features
- Output classes 1875 to 4000 W, for use in tough environments
- 479.7 cfm at 50 Hz, 544.4 cfm at 60 Hz
- 100 W at 50 Hz, 120 W at 60 Hz
- 0.44 A at 50 Hz, 0.5 A at 60 Hz
- Copper or brass tubes
- Fully wired ready for connection
3210500 Standards
RoHS Compliant|UL 1995|UL Listed|cUL Recognized|cCSA C22.2 File No. 236-05|EAC CertifiedSKU #2267160Part Number #3210500UNSPSC40101802UPC00639889375444
