Image provided may only be a representation of
final product and may include optional equipment
3212230
Rittal 3212230 Heat Exchanger
Part Number # 3212230
SKU # 2205969
Rittal 3212230 Key Features
| Brand: | Rittal |
|---|---|
| Part Number # : | 3212230 |
| SKU #: | 2205969 |
| Air Flow Rate: | 164.8/182.5, 164.8/182.5 cfm |
| Ambient Temperature Rating: | 1 to 70, 1 to 70 deg C |
| Amperage Rating: | 0.11/0.13, 0.11/0.13 A |
| Capacity: | 1023, 1023 Btu |
| Dimensions: | 12 in H x 5.9 in W x 3.3 in D |
| Enclosure Type: | IP55 |
| Frequency Rating: | 50/60, 50/60 Hz |
| Pressure Rating: | 1 to 10, 1 to 10 bar |
| Series: | SK Series |
| Type: | 1-Phase Air/Water |
| Mounting type: | Wall |
| Manufacturer Name: | Rittal |
| UNSPSC: | 40101802 |
| UPC: | 00639889375529 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
Rittal 3212230 Heat Exchanger
Brand: Rittal
Part Number: 3212230
Rittal Heat Exchanger, 1-Phase Air/Water, Series: SK Series, 230 VAC, 0.11/0.13 A, 23/27 W Power, 50/60 Hz Frequency, IP55 Enclosure, 164.8/182.5 cfm, 1023 Btu Capacity, 1 to 70 deg C Ambient, 1 to 10 bar Pressure, Wall Mounting, Light Gray, 12 in H x 5.9 in W x 3.3 in D Dimensions
Additional Description: RTL -3212230 A-W HEX 1025BTU 230V 50-60HZ TYPE 12 SIDEMTG, RAL 7035, STEEL 12 50/60HZ, TYPE 12
Catalog Description: SK Air/water heat exchanger, wall-mounted, 0.3 kW, 230 V, 1PH, 50/60 Hz, Water-carrying parts: copper/brass , WHD: 150 x 300 x 85 mm
3212230 Application
Climate Control Solutions Applications3212230 Includes
Plug-In Terminal Strip, Drilling Template, Sealing Mat, Assembly Components3212230 Item Features
- Integral non-return valve for version with e-comfort controller
- Output classes 1875 to 4000 W, for use in tough environments
- 164.8 cfm at 50 Hz, 182.5 cfm at 60 Hz
- 23 W at 50 Hz, 27 W at 60 Hz
- 0.11 A at 50 Hz, 0.13 A at 60 Hz
- Copper or brass tubes
- Fully wired ready for connection
3212230 Standards
RoHS Compliant|EAC CertifiedSKU #2205969Part Number #3212230UNSPSC40101802UPC00639889375529
