Part Number # BSH0551P02A1A
SKU # 2456970
Image Disclaimers Message
Brand: Square D (Schneider Electric)
BSH0551P02A1A
Schneider Electric BSH0551P02A1A
Part Number # BSH0551P02A1A
SKU # 2456970
$1409.11 / Each
Square D (Schneider Electric) BSH0551P02A1A Key Features
| Brand: | Square D (Schneider Electric) |
|---|---|
| Part Number # : | BSH0551P02A1A |
| SKU #: | 2456970 |
| Amperage Rating: | 2.9 to 3.5 A |
| Dimensions: | 5.22 in L |
| Enclosure Type: | IP50/IP54/IP65 |
| Series: | BSH |
| Shaft Size: | 0.35 in Dia x 0.79 in L |
| Special Features: | Brushless Motors |
| Speed: | 4000 rpm |
| Temperature Rating (Degrees F): | -4 to 104 deg F |
| Torque Rating: | 4.07 to 4.25 in-lbf |
| Type: | 3-Phase Multiturn Smooth Shaft End Untapped Natural Convection |
| Country of origin: | US |
| Insulation class: | Class F |
| Mounting type: | Flange |
| Manufacturer Name: | Schneider Electric |
| UNSPSC: | 26101205 |
| UPC: | 03389118198548 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
$1409.11 / Each
Quantity:
- Schneider Electric Square D Lexium 32 Servo Motor, 3-Phase Multiturn Smooth Shaft End Untapped Natural Convection, Series: BSH, Brushless Motors Special Features, 480 V, 2.9 to 3.5 A, 4000 rpm Speed, IP50/IP54/IP65 Enclosure, 0.35 in Dia x 0.79 in L Shaft, 4.07 to 4.25 in-lbf Torque, Flange Mounting, -4 to 104 deg F, Insulation Class: Class F, 5.22 in L Dimensions
BSH0551P02A1A Item Features
- For the leading edge Lexium 32 simplifies all aspects in the machine life cycle from engineering to maintenance
- A speed bandwidth of 1600 Hz provides outstanding response
- With a power density of 548 W/l Lexium 32 packs maximum power into minimum volume
- This saves on cabinet space and size, reduces the machine footprint and decreases costs
- Powerful integration software simplifies the entire process from planning to commissioning
- The new auto tuning function makes tuning easier than ever before
- Lexium 32 offers a host of features for rapid installation and maintenance
- Lexium 32 supports a wide selection of interfaces for fast integration into architectures
- Communication boards, encoder options and accessories adapt your Lexium 32 solution
- Leverage the full power of existing assets such as applications or legacy motors
- Safe torque off on board (IEC/EN 61800-5-2) for shorter downtime and less wiring
- Without holding brake
- 4.25 in-lbf at 400/480 V 3 ph and 4.07 in-lbf at 230 V 1 ph
- https://www.youtube.com/embed/4-v0hzgyQlg
BSH0551P02A1A Standards
ECCN: EAR99|Green Premium Listed|REACH Compliant|RoHS Compliant|UL E208613|WEEE Certified|PROP65: This product can expose you to chemicals including: Lead and lead compounds which is known to the State of California to cause Carcinogen and Reproductive harm. For more information go to www.p65warnings.ca.govSKU #2456970Part Number #BSH0551P02A1AUNSPSC26101205UPC03389118198548
