Schneider Electric QGL22225 Powerpact Q Molded Case Circuit Breaker
Part Number # QGL22225
SKU # 2407993
$1545.14 / Each
Schneider Electric QGL22225 Key Features
| Brand: | Schneider Electric |
|---|---|
| Part Number # : | QGL22225 |
| SKU #: | 2407993 |
| Actuator Type: | Toggle |
| Amperage Rating: | 225 A |
| Dimensions: | 6.47 in H x 3 in W x 3.93 in D |
| Frame: | Q |
| Frequency Rating: | 50/60 Hz |
| Interrupt Rating: | 65 kA |
| Number of Poles: | 2 |
| Phase: | 1 |
| Temperature Rating (Degrees F): | 104 deg F |
| Trip Range: | 1200 to 2400 A |
| Trip Type: | Thermal Magnetic, Thermal/Magnetic |
| Type: | Type QG |
| Wire Size: | 4 AWG to 300 kcmil Al/Cu |
| Connection type: | Line/Load Lugs |
| Country of origin: | MX |
| Mounting type: | Unit |
| Manufacturer Name: | Schneider Electric |
| UNSPSC: | 39121616 |
| UPC: | 00785901603467 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
$1545.14 / Each
Quantity:
- Square D PowerPact Q Molded Case Circuit Breaker, Type QG, 240 V AC, 225 A, 50/60 Hz Frequency, 65 kA Interrupt, Q Frame, Thermal Magnetic Trip, 1200 to 2400 A Trip, 2 Pole, 1 ph, Toggle Actuator, Line/Load Lugs Connection, 4 AWG to 300 kcmil Al/Cu Wire, Unit Mounting, 104 deg F, 6.47 in H x 3 in W x 3.93 in D Dimensions
QGL22225 Application
OEM Commercial, Industrial Markets, Overload, Short Circuit Protection, Overcurrent Protection and Switching on AC SystemsQGL22225 Item Features
- Available in 2 or 3 pole design
- Common accessories across the range
- Confidence and power reliability
QGL22225 Standards
RoHS Compliant|UL 489|CSA C22.2 No. 5-02|IEC 60947-2|PROP65: Cancer and Reproductive Harm - www.p65Warnings.ca.govSKU #2407993Part Number #QGL22225UNSPSC39121616UPC00785901603467
