Part Number # 14FUF32AC
SKU # 2289279
Image Disclaimers Message
14FUF32AC
Siemens 14FUF32AC Motor Starter
Part Number # 14FUF32AC
SKU # 2289279
$923.50 / Each
Typical price:$1847.00 / Each
Siemens 14FUF32AC Key Features
| Brand: | Siemens |
|---|---|
| Part Number # : | 14FUF32AC |
| SKU #: | 2289279 |
| Action: | Non-Reversing |
| Amperage Rating: | 45, 45 A |
| Auxiliary Contact Rating: | 1NO |
| Coil Voltage: | 220 to 240/440 to 480, 220 to 240/440 to 480 V AC, 220 to 240/440 to 480 VAC |
| Dimensions: | 8.13 in H x 5.75 in W x 4 in D |
| Enclosure Type: | NEMA 2/Open, Open |
| Frequency Rating: | 60, 60 Hz |
| Motor Power: | 10 hp, 15 hp, 25 hp |
| Number of Poles: | 3 |
| Operating Cycles: | 10000000, 10000000 Cycles |
| Operating Temperature: | -4 to 104, -4 to 104 deg F |
| Overload Relay: | Solid State, Solid-State |
| Reset Type: | Automatic/Manual/Remote |
| Setting: | 52, 52 A |
| Timing: | 3, 3 s |
| Type: | Class 14 Full Voltage |
| Wattage: | 8.6, 8.6 W |
| Connection type: | Screw |
| Country of origin: | MX |
| Manufacturer Name: | Siemens |
| UNSPSC: | 39121521 |
| UPC: | 00783087817913 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
$923.50 / Each
Typical price:$1847.00 / Each
Quantity:
- Siemens Motor Starter, Class 14 Full Voltage, 600 VAC, 45 A, 60 Hz Frequency, 8.6 W Wattage, 10 hp, 15 hp, 25 hp Motor, 220 to 240/440 to 480 V AC Coil, 3 Pole, Setting: 52 A, 3 s Timing, Automatic/Manual/Remote Reset, Screw Connection, Non-Reversing Action, Solid-State Overload Relay, 1NO Auxiliary, Open Enclosure, 10000000 Cycles Operating Cycles, -4 to 104 deg F Operating, 8.13 in H x 5.75 in W x 4 in D Dimensions
14FUF32AC Application
For single-phase, polyphase motor and general purpose applications14FUF32AC Item Features
- ESP 200 SS overload, motor match half sizes, dual coils
- 10 hp at 200/208 VAC, 15 hp at 220/230 VAC, 25 hp at 460/480/575/600 VAC
- NEMA Size 2
14FUF32AC Standards
UL E14900, cUL, CSASKU #2289279Part Number #14FUF32ACUNSPSC39121521UPC00783087817913
