3NA3807
Siemens 3NA3807 Sentron Low Voltage Fuse Link
Part Number # 3NA3807
SKU # 2238294
$90.57 / 3Each
Typical price:$109.50 / Each
Siemens 3NA3807 Key Features
| Brand: | Siemens |
|---|---|
| Part Number # : | 3NA3807 |
| SKU #: | 2238294 |
| Amperage Rating: | 20, 20 A |
| Dimensions: | 77.8 mm L x 52.5 mm W x 21 mm D |
| Rated Breaking Capacity: | 120, 120 kA |
| Temperature Rating (Degrees F): | -20 to 50, -20 to 50 deg C |
| Type: | HRC Design |
| Country of origin: | DE |
| Material: | Ceramic |
| Manufacturer Name: | Siemens |
| UNSPSC: | 39121626 |
| UPC: | 00754554152431 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
$90.57 / 3Each
Typical price:$109.50 / Each
Quantity:
- Sentron Low Voltage Fuse Link, HRC Design, 500 V AC, 20 A, Rated Breaking Capacity: 120 kA, -20 to 50 deg C Temperature Rating, Ceramic Material, 77.8 mm L x 52.5 mm W x 21 mm D Dimensions
3NA3807 Application
For protection applications3NA3807 Item Features
- Fuse links with combination alarm signal the tripping of a fuse by a clear color change from red to white, enables fast identification and replacement of the tripped fuselinks
- Insulated grip lugs made of metal are integrated in the top and bottom covers of the fuse link in molded plastic and provide greater safety during replacement
- Standard series with front indicator, the front-mounted red indicator signals the tripping of a fuse
- LV HRC fuse links are always equipped with silver plated contact pins, ensures the long term operational safety of the plant, non-corroding and have less contact resistance
- Class gG, Size NH000
- Non-insulated grip lugs
3NA3807 Standards
IEC 60269-2/IEC 60269-4SKU #2238294Part Number #3NA3807UNSPSC39121626UPC00754554152431
