Brand: Siemens
Siemens 3NE1437-2 Sentron Low Voltage Fuse Link
Part Number # 3NE1437-2
SKU # 2203292
$1766.79 / 3Each
$6033.00/Each
Siemens 3NE1437-2 Key Features
Brand: Siemens
Part Number # 3NE1437-2
SKU #2203292
Amperage Rating: 710 A
Dimensions: 151 mm H x 82.1 mm W
Rated Breaking Capacity: 100 kA
Series: 3NE
Suitable For Use With: SITOR Semiconductor Fuse System
Temperature Rating (Degrees F): -20 to 50 deg C
Type: HRC Design
Voltage Rating: 690 VAC
Country of origin: DE
Material: Ceramic
Mounting type: Vertical
Manufacturer Name: Siemens
UNSPSC: 39121626
UPC: 00754554950440
$1766.79 / 3Each
$6033.00/Each
Siemens 3NE1437-2 Sentron Low Voltage Fuse Link
Sentron Low Voltage Fuse Link, HRC Design, Series: 3NE, 690 VAC, 710 A, Rated Breaking Capacity: 100 kA, -20 to 50 deg C Temperature Rating, Vertical Mount, For Use With: SITOR Semiconductor Fuse System, Ceramic Material, 151 mm H x 82.1 mm W Dimensions
Additional Description: SIEM-3NE1437-2 (N) SITOR SET FUSES, 710A, 690VAC, CLASS GR NON-CANCELABLE, NON-RETURNABLE 400VAC
Catalog Description: SITOR fuse link, with blade contacts, NH3, In 710 A, gR, Un AC 690 V, Un DC 440V, Front indicator
3NE1437-2 Application
For protection of converter equipment against short circuits3NE1437-2 Item Features
- GR operating class of the fuse link
- Front indicator with blade contacts
- NH3 size of fuse system
- 3NE circuit breaker/design
- 72 W power loss
3NE1437-2 Standards
CE/CCC Certified|UL Recognized|UL 248-4SKU #2203292Part Number #3NE1437-2UNSPSC39121626UPC00754554950440
