Part Number # 3NW7334
SKU # 2261166
Image provided may only be a representation of
final product and may include optional equipment
3NW7334
Siemens 3NW7334 Sentron Cylindrical Fuse Holder
Part Number # 3NW7334
SKU # 2261166
Siemens 3NW7334 Key Features
| Brand: | Siemens |
|---|---|
| Part Number # : | 3NW7334 |
| SKU #: | 2261166 |
| Amperage Rating: | 20, 20 A |
| Dimensions: | 81 mm H x 54 mm W x 64 mm D |
| Fuse Diameter: | 32, 32 mm |
| Fuse Length: | 8, 8 mm |
| Number of Poles: | 3 |
| Suitable For Use With: | Cylindrical Fuse System |
| Temperature Rating (Degrees F): | -5 to 40, -5 to 40 deg C |
| Type: | SZ NH3 Sealable |
| Wire Size: | 0.5 to 10, 0.5 to 10 sq-mm |
| Country of origin: | DE |
| Material: | Ceramic/Plastic |
| Mounting type: | Surface |
| Manufacturer Name: | Siemens |
| UNSPSC: | 39121626 |
| UPC: | 00754554944579 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
Siemens 3NW7334 Sentron Cylindrical Fuse Holder
Brand: Siemens
Part Number: 3NW7334
Siemens Sentron Cylindrical Fuse Holder, SZ NH3 Sealable, 400 VAC, 20 A, 3 Pole, 0.5 to 10 sq-mm Wire, Surface Mount, 8 mm Fuse Length, 32 mm Fuse Dia, -5 to 40 deg C, For Use With: Cylindrical Fuse System, Ceramic/Plastic, 81 mm H x 54 mm W x 64 mm D
Additional Description: SIEM-3NW7334 (N) FUSE HOLDER,3-POLE,20A,8.5X31MM FUSE,LED NON-CANCELABLE, NON-RETURNABLE
Catalog Description: SENTRON, cylindrical fuse holder, 8x32 mm, 3-pole, In 20 A, Un AC 400 V, LED signal detector
3NW7334 Application
For control circuit protection applications3NW7334 Item Features
- Devices with pole number 1P+N are available in a single modular width, this reduces the footprint by 50%
- The sliding catch for type ranges 8 x 32 mm and 10 x 38 mm enables the removal of individual devices from the assembly
- Space for a spare fuse in the plug-in module enables the fast replacement of fuses, this saves time and money and increases system availability
- A flashing LED signals that a fuse link has been tripped, this enables fast detection during runtime
- 0.5 to 10 sq-mm rigid/stranded/finely stranded wire size
3NW7334 Standards
UL 512SKU #2261166Part Number #3NW7334UNSPSC39121626UPC00754554944579
