Brand: Siemens
Siemens 3NW8222-1 Sentron Cylindrical Fuse Link
Image Disclaimers Message
Brand: Siemens
Siemens 3NW8222-1 Sentron Cylindrical Fuse Link
Brand: Siemens
Siemens 3NW8222-1 Sentron Cylindrical Fuse Link
Part #:3NW8222-1
SKU #: 2303270
$162.30/10EA
Key Features
Part #:3NW8222-1
SKU #: 2303270
Brand: Siemens
Amperage Rating: 63, 63 A
Dimensions: 22.2 mm Dia x 58 mm L
Rated Breaking Capacity: 100, 100 kA
Suitable For Use With: Cylindrical Fuse System
Type: SZ NH2 Class aM
$162.30/10EA
- Devices with pole number 1P+N are available in a single modular width
- This reduces the footprint by 50%
- The sliding catch for type ranges 8 x 32 mm and 10 x 38 mm enables the removal of individual devices from the assembly
- Space for a spare fuse in the plug-in module enables the fast replacement of fuses
- This saves time and money and increases system availability
Specifications
Brand: Siemens
Amperage Rating: 63, 63 A
Dimensions: 22.2 mm Dia x 58 mm L
Rated Breaking Capacity: 100, 100 kA
Suitable For Use With: Cylindrical Fuse System
Type: SZ NH2 Class aM
Voltage Rating: 500, 500 VAC
Country of origin: DE
Material: Ceramic/Plastic
Mounting type: Surface
Manufacturer Name: Siemens
UNSPSC: 39121626
UPC: 00040892932393
Siemens 3NW8222-1 Sentron Cylindrical Fuse Link
Siemens Sentron Cylindrical Fuse Link, SZ NH2 Class aM, 500 VAC, 63 A, 100 kA Rated Breaking Capacity, Surface Mount, For Use With: Cylindrical Fuse System, Ceramic/Plastic, 22.2 mm Dia x 58 mm L
Additional Description: SIEM-3NW8222-1 (N) NFC CYLINDRICAL FUSE,63A,500V,22X58MM NON-CANCELABLE, NON-RETURNABLE
Catalog Description: SENTRON, cylindrical fuse link, 22 x 58 mm, 63 A, AM, Un AC 500 V
Item FeaturesFor supplementary protection and residential buildings applications
Item Features
Item FeaturesNFC Approved|WEEE (2012/19/EU)|CE Certified|DIN EN 61346-2|DIN EN 81346-2|IEC 60269-1|IEC 60269-2|IEC 60269-3|NFC 60-200|NFC 63-210|NFC 63-211|NBNC 63269-2|CEI 32-4|CEI 32-12
