Part Number # 3RA61201EP32
SKU # 2190546
Image Disclaimers Message
Brand: Siemens
3RA61201EP32
Siemens 3RA61201EP32 Compact Starter
Part Number # 3RA61201EP32
SKU # 2190546
$1123.10 / Each
Typical price:$1475.00 / Each
Siemens 3RA61201EP32 Key Features
| Brand: | Siemens |
|---|---|
| Part Number # : | 3RA61201EP32 |
| SKU #: | 2190546 |
| Amperage Rating: | 29/17.6/12.8 A, 32 |
| Auxiliary Contact Rating: | 1NC, 1NC-1NO-1CO |
| Coil Voltage: | 110 to 240, 110 to 240 V AC/DC, 110 to 240 VAC/VDC |
| Dimensions: | 170 mm H x 45 mm W x 165 mm D |
| Enclosure Type: | IP20 |
| Frequency Rating: | 50/60, 50/60 Hz |
| Full Load Current: | 32 A |
| Motor Power: | 20, 7-1/2 hp, 10 hp, 20 hp |
| Number of Poles: | 3 |
| Operating Cycles: | 10000000, 10000000 Cycles |
| Operating Temperature: | -20 to 60, -20 to 60 deg C |
| Overload Relay: | Class 10/20 Adjustable Electronic, Solid State |
| Phase: | 3 |
| Reset Type: | Automatic/Manual |
| Series: | 3RA6 |
| Type: | Compact DOL Load Feeder, Fuseless Snap-On Mount |
| Wattage: | 11, 15/11 kW |
| Connection type: | Screw, Threaded |
| Country of origin: | DE |
| Manufacturer Name: | Siemens |
| UNSPSC: | 39121521 |
| UPC: | 00662643359084 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
$1123.10 / Each
Typical price:$1475.00 / Each
Quantity:
- SIRIUS Starter, Compact DOL Load Feeder, 29/17.6/12.8 A, 50/60 Hz Frequency, 15/11 kW Wattage, 7-1/2 hp, 10 hp, 20 hp Motor, 110 to 240 V AC/DC Coil, 3 Pole, Automatic/Manual Reset, 3 ph, Screw Connection, Class 10/20 Adjustable Electronic Overload Relay, 32 A Full Load, 1NC-1NO-1CO Auxiliary, IP20 Enclosure, 10000000 Cycles Operating Cycles, -20 to 60 deg C Operating, 170 mm H x 45 mm W x 165 mm D Dimensions
3RA61201EP32 Item Features
- 15 kW at 400 VAC, 11 kW at 500/690 VAC
- 29 A at 400 VAC, 17.6 A at 500 VAC, 12.8 A at 690 VAC
- 7-1/2 hp at 200/208 VAC, 10 hp at 220/230 VAC, 20 hp at 460/480 VAC
3RA61201EP32 Standards
RoHS Compliant|REACH Article 33|UL Listed|CE Certified|CSA Certified|EAC Approved|C-Tick|VDE Approved|Bureau Veritas Certified|Lloyds Registered|PRS Certified|RINA Certified|RMRS Approved|DNV-GL Approved|CCC Certified|IEC/EN 60947-6-2SKU #2190546Part Number #3RA61201EP32UNSPSC39121521UPC00662643359084
