Part Number # 3RB2056-1FW2
SKU # 2129883
3RB2056-1FW2
Siemens 3RB2056-1FW2 SIRIUS Overload Relay
Part Number # 3RB2056-1FW2
SKU # 2129883
$509.14 / Each
Typical price:$891.00 / Each
Siemens 3RB2056-1FW2 Key Features
| Brand: | Siemens |
|---|---|
| Part Number # : | 3RB2056-1FW2 |
| SKU #: | 2129883 |
| Amperage Rating: | 50 to 200 A |
| Coil Voltage: | 1000 V AC |
| Contact Rating: | 200 A at 1000 V AC |
| Dimensions: | 119 mm H x 120 mm W x 155 mm D |
| Terminal Type: | Straight Through Transformer |
| Type: | Solid-State |
| UNSPSC: | 39122330 |
| UPC: | 00040892624403 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
$509.14 / Each
Typical price:$891.00 / Each
Quantity:
- Siemens SIRIUS, 3RB2056-1FW2, Overload Relay, Solid-State, 50 to 200 A, 50/60 Hz Frequency, 1000 V AC Coil, 1NO-1NC 1 Form A/1 Form B Contact Form, 200 A at 1000 V AC Contact, 3 Pole, Surface Mounting, Straight Through Transformer Terminal, IP20 Enclosure, -25 to 60 deg C, 119 mm H x 120 mm W x 155 mm D Dimensions
3RB2056-1FW2 Application
Motor Protection Applications3RB2056-1FW2 Item Features
- Reset button
- Internal power supply
- Overload protection, phase failure protection and unbalance protection
- Class 10
- Devices are manufactured in accordance with environmental guidelines and contain environmentally friendly and reusable materials
- Size S6
- Stand alone installation
- Manual and automatic reset
- Test function and self-monitoring
- 4 A at 24/110/120/125 VAC, 3 A at 230 VAC operating current of auxiliary contacts at AC-15, 2 A at 24 VDC, 0.55 A at 60 VDC, 0.3 A at 110/125 VDC, 0.11 A at 220 VDC operating current of auxiliary contacts at DC-13
- Switch position indicators
- -40 to 80 deg C environmental conditions
- https://www.youtube.com/watch?v=lvThW3cHXnA\u200b|https://www.youtube.com/watch?v=r3MRdVQEztw|https://www.youtube.com/watch?v=4AdAIl-ElSk
3RB2056-1FW2 Standards
CE Marked|CCC Marked|EAC Rated|RoHS Compliant|CSA Certified|UL Listed|EAC Approved|C-Tick|ATEX Certified|ABS Approved|LRS Listed|RINA Certified|DNV-GL ApprovedSKU #2129883Part Number #3RB2056-1FW2UNSPSC39122330UPC00040892624403
Image provided may only be a representation of final product and may include optional equipment
