Part Number # 3RF2920-0GA16
SKU # 2124608
Image provided may only be a representation of
final product and may include optional equipment
3RF2920-0GA16
Siemens 3RF2920-0GA16 SIRIUS Solid State Relay
Part Number # 3RF2920-0GA16
SKU # 2124608
Siemens 3RF2920-0GA16 Key Features
| Brand: | Siemens |
|---|---|
| Part Number # : | 3RF2920-0GA16 |
| SKU #: | 2124608 |
| Amperage Rating: | 20 |
| Coil Voltage: | 18 to 30 VDC, 20.5 to 26.5 VAC |
| Dimensions: | 111 mm H x 45 mm W, 45 mm W x 111 mm H |
| Enclosure Type: | IP20 |
| Frequency Rating: | 50/60 |
| Series: | 3RF |
| Specifications: | 18 to 30 V DC, 20.5 to 26.5 V AC Coil Voltage, 20 A, 50/60 Hz, Clip-On Mount, IP20 Enclosure, 25 to 60 deg C, 18 to 30 VDC, 20.5 to 26.5 VAC Coil Voltage, 20 A, 50/60 Hz, Clip-On Mount, IP20 Enclosure, 25 to 60 deg C |
| Temperature Rating (Degrees F): | -25 to 60 |
| Terminal Type: | Screw |
| Type: | 1-Phase Extended Load Monitoring Semiconductor |
| Country of origin: | CZ |
| Mounting type: | Clip-On |
| Manufacturer Name: | Siemens |
| UNSPSC: | 32121702 |
| UPC: | 00754554899695 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
Siemens 3RF2920-0GA16 SIRIUS Solid State Relay
Brand: Siemens
Part Number: 3RF2920-0GA16
Siemens SIRIUS Solid State Relay, 1-Phase Extended Load Monitoring Semiconductor, Series: 3RF, 18 to 30 VDC, 20.5 to 26.5 VAC Coil Voltage, 20 A, 50/60 Hz, Clip-On Mount, IP20 Enclosure, 25 to 60 deg C, 45 mm W x 111 mm H
Additional Description: SIEM-3RF2920-0GA16 MONITORING MODULE,24V COIL,20A,600VAC
Catalog Description: Load Monitoring Module Enhanced Solid State, SIRIUS SC 24 VAC/DC Control Voltage Current Rating 20 Amps Power Voltage 400-600 VAC Width = 45mm UL File E143112 in Vol.1 Sec.8
3RF2920-0GA16 Application
For monitoring one or more load and resistive/inductive loads3RF2920-0GA16 Standards
CSA Certified|CE Certified|UL Listed|EAC Certified|RMC Certified|WEEE (2012/19/EU)SKU #2124608Part Number #3RF2920-0GA16UNSPSC32121702UPC00754554899695
