3RT1264-6AF36
Siemens 3RT1264-6AF36 SIRIUS IEC Contactor
Part Number # 3RT1264-6AF36
SKU # 2338147
Siemens 3RT1264-6AF36 Key Features
| Brand: | Siemens |
|---|---|
| Part Number # : | 3RT1264-6AF36 |
| SKU #: | 2338147 |
| Coil Power Rating: | 630 VA Pickup, 7.4 VA Holding |
| Coil Voltage: | 110 VAC, 127 VDC |
| Contact Configuration: | 3NO |
| Contact Rating: | A600/Q600 |
| Dimensions: | 210 mm H x 145 mm W x 206 mm D |
| Enclosure Type: | IP00 |
| Frequency Rating: | 50/60, 50/60 Hz |
| Number of Auxiliary Contacts: | 4 |
| Number of Poles: | 3 |
| Operating Cycles: | 10000000 Cycles Contactor/Typical |
| Operating Temperature: | -25 to 60, -25 to 60 deg C |
| Size: | Size S10 |
| Terminal Type: | Busbar/Screw |
| Type: | Vacuum |
| Wattage: | 110, 110 kW |
| Connection type: | Screw |
| Country of origin: | DE |
| Mounting type: | Panel/Screw Fixing |
| Power factor: | 0.9 Closing, Holding |
| Manufacturer Name: | Siemens |
| UNSPSC: | 39121529 |
| UPC: | 00754554772851 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
Siemens 3RT1264-6AF36 SIRIUS IEC Contactor
Brand: Siemens
Part Number: 3RT1264-6AF36
Siemens SIRIUS IEC Contactor, Vacuum, 110 VAC, 127 VDC Coil, 225 A Maximum Load Current, 630 VA Pickup, 7.4 VA Holding Coil, 3 Pole, 50/60 Hz Frequency, 110 kW Wattage, Non-Reversing Contact, 3NO Contact Configuration, 4 Auxiliary Contacts, A600/Q600 Contact, Power Factor: 0.9 Closing, Holding, Screw Connection, Size S10 Size, Busbar/Screw Terminal, IP00 Enclosure, 10000000 Cycles Contactor/Typical Operating Cycles, -25 to 60 deg C Operating, Panel/Screw Fixing Mounting, 210 mm H x 145 mm W x 20
Additional Description: SIEM-3RT1264-6AF36 CONTACTOR VAC S10 225A 110-127V 3P BAR
Catalog Description: Contactor,IEC,Sirius,Vacuum 3 Pole,Non-Reversing 110 - 127 AC/DC Coil Frame Size S10,225A Panel Mount 2 NO ( & ) 2 NC Auxiliaries No Suppression Lugs (Not Included) Terminals UL File E31519 in Vol.11 Sec. 3
3RT1264-6AF36 Application
Switching Motors Applications3RT1264-6AF36 Item Features
- Without suppression lugs
- 10000000 of the contactor/typical, 10000000 of the contactor with added auxiliary switch block/typical, 5000000 of the Contactor With Added Electronics Compatible Auxiliary Switch Block/Typical
- Integrated coil circuit
- 3-phase
3RT1264-6AF36 Standards
UL File No. E31519 (Vol 11 Sec 3)SKU #2338147Part Number #3RT1264-6AF36UNSPSC39121529UPC00754554772851
