Part #:3SU10000AA200AA0
SKU #: 2338336
$9.34/EA
Key Features
Part #:3SU10000AA200AA0
SKU #: 2338336
Brand: Siemens
Bezel/Housing: Plastic
Enclosure Type: NEMA 1/2/3/3R/4/4X/12/13/IP66/IP67/IP69/IP69K
Environmental Conditions: -25 to 70 deg C Operating, -40 to 80 deg C Storage, 10 to 95% Relative Humidity
Finish: Black
Operator Type: Flat Button, Flat Button/Latching/Push-Unlatch, Flat Button/Latching/Push-to-Unlatch
$9.34/EA
- Direct connection of the enclosure to AS-interface or IO-Link
- Direct connection in the control cabinet to PROFINET, IO-Link or AS-interface
- Can be integrated easily via TIA portal
- Self-holding function of the actuator when mounting
- Twist prevention integrated into patented holder design
- Stackable contact modules
- Self-explanatory and fast installation using one hand
- Components can be mounted with holder removed
- Media resistance (chemicals) thanks to solid stainless steel and high grade plastics
- Mechanical endurance of 10 x 10^6 operating cycles
- Reliable, friction locked fixing with just one screw
- Design stability according to use
- Simple geometry for mounting holes
- Without module and holder
Specifications
Brand: Siemens
Bezel/Housing: Plastic
Enclosure Type: NEMA 1/2/3/3R/4/4X/12/13/IP66/IP67/IP69/IP69K
Environmental Conditions: -25 to 70 deg C Operating, -40 to 80 deg C Storage, 10 to 95% Relative Humidity
Finish: Black
Operator Type: Flat Button, Flat Button/Latching/Push-Unlatch, Flat Button/Latching/Push-to-Unlatch
Series: 3SU10
Size: 22, 22 mm
Temperature Rating (Degrees F): -25 to 70, -25 to 70 deg C
Terminal Type: Screw
Type: Round
Color: Black/Red
Country of origin: CN
Material: Plastic
Mounting type: Flush
Manufacturer Name: Siemens
UNSPSC: 39122216
UPC: 00804766061912
Item FeaturesFor use in extreme environments, standard industrial and operation in marine applications
Item Features
Item FeaturesCSA Certified|UL Listed|EAC Certified|CE Certified|ABS Approved|Lloyds Register|PRS Approved|RINA Approved|RMRS Approved|DNV-GL Approved|IEC 60947-1|IEC 60947-5-1|EN 60947-1|EN 60947-5-1|WEEE 2012/19/EU
