Part Number # 40GP32AA
SKU # 2430383
Image Disclaimers Message
40GP32AA
Siemens 40GP32AA Power Contactor, 110 to 120/220 to 240 VAC V Coil, 60 A, 1NO Contact
Part Number # 40GP32AA
SKU # 2430383
Siemens 40GP32AA Key Features
| Brand: | Siemens |
|---|---|
| Part Number # : | 40GP32AA |
| SKU #: | 2430383 |
| Coil Power Rating: | 218 VA Pickup, 25 VA Holding |
| Coil Voltage: | 110 to 120/220 to 240 VAC |
| Contact Configuration: | 1NO |
| Dimensions: | 4.88 in H x 5.75 in W x 4 in D |
| Enclosure Type: | Open |
| Frequency Rating: | 60 Hz |
| Operating Cycles: | 10000000 Cycles Contactor/Typical |
| Operating Temperature: | -20 to 40 deg C |
| Size: | SZ 2.5 |
| Terminal Type: | Screw |
| Wattage: | 8.6 W |
| Connection type: | Screw |
| Country of origin: | MX |
| Mounting type: | Surface |
| Manufacturer Name: | Siemens |
| UNSPSC: | 39121529 |
| UPC: | 00783087068377 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
Siemens 40GP32AA Power Contactor, 110 to 120/220 to 240 VAC V Coil, 60 A, 1NO Contact
Brand: Siemens
Part Number: 40GP32AA
Siemens Power Contactor, 110 to 120/220 to 240 VAC Coil, 60 A Maximum Load Current, 218 VA Pickup, 25 VA Holding Coil, 60 Hz Frequency, 8.6 W Wattage, Non-Reversing Contact, 1NO Contact Configuration, Screw Connection, SZ 2.5 Size, Screw Terminal, Open Enclosure, 10000000 Cycles Contactor/Typical Operating Cycles, -20 to 40 deg C Operating, Surface Mounting, 4.88 in H x 5.75 in W x 4 in D Dimensions
Additional Description: SIEM-40GP32AA CONTACTOR, SZ2.5,3PH,OPN,120/240V,
Catalog Description: Non-reversing contactor, Size 2 1/2, Three phase full voltage, Contactor amp rating 60A, 3 wire (NO aux included), 110-120/220-240VAC 60Hz coil, Non-combination type, Enclosure NEMA type (open), No enclosure
40GP32AA Item Features
- Three phase full voltage
- 3 number of wires (no auxiliary include)
- Without enclosure
- 10000000 mechanical service life of the main contacts typical
SKU #2430383Part Number #40GP32AAUNSPSC39121529UPC00783087068377
