Part #:5SD480
SKU #: 2212477
$45.20/5EA
Key Features
Part #:5SD480
SKU #: 2212477
Brand: Siemens
Amperage Rating: 30, 30 A
Dimensions: 22.5 mm Dia x 49 mm L
Rated Breaking Capacity: 50, 50 kA
Temperature Rating (Degrees F): -5 to 45, -5 to 45 deg C
Type: Extra Fast Diazed Silized
$45.20/5EA
- Silized semiconductor fuses have an extremely compact design, this means they have a very small footprint-particularly the neozed version
- Rugged and well-known diazed design complies with IEC 60269-3
- It is globally renowned and can be used in many countries
- Class gR, Size DIII
Specifications
Brand: Siemens
Amperage Rating: 30, 30 A
Dimensions: 22.5 mm Dia x 49 mm L
Rated Breaking Capacity: 50, 50 kA
Temperature Rating (Degrees F): -5 to 45, -5 to 45 deg C
Type: Extra Fast Diazed Silized
Voltage Rating: 500, 500 VAC
Country of origin: DE
Material: Ceramic
Mounting type: Rail/Screw-In
Manufacturer Name: Siemens
UNSPSC: 39121626
UPC: 00754554214771
Siemens 5SD480 Sentron Fuse Link
Sentron Fuse Link, Extra Fast Diazed Silized, 500 VAC, 30 A, Rated Breaking Capacity: 50 kA, -5 to 45 deg C Temperature Rating, Rail/Screw-In Mount, Ceramic Material, 22.5 mm Dia x 49 mm L Dimensions
Additional Description: SIEM-5SD480 SILIZED FUSE LINK,30A,AC/DC,500V
Catalog Description: SILIZED FUSE LINK,30A,AC/DC,500V THREAD E27, 30A EXTRA FAST, SIZE DII F.SEMICONDUCTOR PROTECTION SILIZED FUSE LINK 500V
Item FeaturesFor supplementary protection and semi-conductor protection
Item Features
Item FeaturesIEC 60269|VDE 0636|VDE 0635
