5SJ4132-8HG42
Siemens 5SJ4132-8HG42 Sentron Miniature Circuit Breaker
Part Number # 5SJ4132-8HG42
SKU # 2326045
$62.74 / Each
Typical price:$244.00 / Each
Siemens 5SJ4132-8HG42 Key Features
| Brand: | Siemens |
|---|---|
| Part Number # : | 5SJ4132-8HG42 |
| SKU #: | 2326045 |
| Actuator Type: | Handle |
| Amperage Rating: | 32, 32 A |
| Dimensions: | 121 mm H x 18 mm W x 76 mm D |
| Enclosure Type: | IP20/IP40 |
| Frame: | HSJ |
| Frequency Rating: | 50/60, 50/60 Hz |
| Interrupt Rating: | 10, 10 kA |
| Number of Poles: | 1 |
| Series: | 5SJ |
| Temperature Rating (Degrees F): | -25 to 55, -25 to 55 deg C |
| Trip Type: | Thermal Magnetic, Thermal/Magnetic |
| Wire Size: | 14 to 4, 14 to 4 AWG |
| Connection type: | Screw |
| Country of origin: | DE |
| Mounting type: | DIN Rail |
| Manufacturer Name: | Siemens |
| UNSPSC: | 39121601 |
| UPC: | 00754554959450 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
$62.74 / Each
Typical price:$244.00 / Each
Quantity:
- Sentron Miniature Circuit Breaker, Series: 5SJ, 277/480 V AC, 32 A, 50/60 Hz Frequency, 10 kA Interrupt, HSJ Frame, Thermal Magnetic Trip, 1 Pole, Handle Actuator, Screw Connection, 14 to 4 AWG Wire, IP20/IP40 Enclosure, DIN Rail Mounting, -25 to 55 deg C, 121 mm H x 18 mm W x 76 mm D Dimensions
5SJ4132-8HG42 Application
Branch Circuit Protection Applications5SJ4132-8HG42 Item Features
- Can be used globally for all applications in residential, non-residential and industrial buildings, this facilitates the planning of installations and enhances export opportunities
- The devices can be used according to IEC/EN 60898-1 and UL 489, which means these devices can be installed anywhere in the world
- Can be used for both AC voltage and DC voltage up to 125 VAC
- Rated making and breaking capacity up to 14 kA in according with UL 489 and up to 15 kA in according with IEC 60947-2
- Fast mounting with busbars up to 115 A and feeder terminals up to 50 sq-mm
- Class D trip
5SJ4132-8HG42 Standards
CSA C22.2 No. 5-02|UL 489|UL 489ASKU #2326045Part Number #5SJ4132-8HG42UNSPSC39121601UPC00754554959450
