Part Number # 5SJ4145-7HG40
SKU # 2318274
Image provided may only be a representation of
final product and may include optional equipment
5SJ4145-7HG40
Siemens 5SJ4145-7HG40 Sentron Miniature Circuit Breaker
Part Number # 5SJ4145-7HG40
SKU # 2318274
Siemens 5SJ4145-7HG40 Key Features
| Brand: | Siemens |
|---|---|
| Part Number # : | 5SJ4145-7HG40 |
| SKU #: | 2318274 |
| Actuator Type: | Handle |
| Amperage Rating: | 6, 6 A |
| Dimensions: | 90 mm H x 18 mm W x 70 mm D |
| Enclosure Type: | IP20/IP40 |
| Frame: | HSJ |
| Frequency Rating: | 50/60, 50/60 Hz |
| Interrupt Rating: | 14, 14 kA |
| Number of Poles: | 1 |
| Series: | 5SJ |
| Temperature Rating (Degrees F): | -25 to 55, -25 to 55 deg C |
| Trip Type: | Thermal Magnetic, Thermal/Magnetic |
| Wire Size: | 14 to 4, 14 to 4 AWG |
| Connection type: | Screw |
| Country of origin: | DE |
| Mounting type: | DIN Rail |
| Manufacturer Name: | Siemens |
| UNSPSC: | 39121601 |
| UPC: | 00754554932705 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
Siemens 5SJ4145-7HG40 Sentron Miniature Circuit Breaker
Brand: Siemens
Part Number: 5SJ4145-7HG40
Sentron Miniature Circuit Breaker, Series: 5SJ, 240 VAC, 6 A, 50/60 Hz Frequency, 14 kA Interrupt, HSJ Frame, Thermal/Magnetic Trip, 1 Pole, Handle Actuator, Screw Connection, 14 to 4 AWG Wire, IP20/IP40 Enclosure, DIN Rail Mounting, -25 to 55 deg C, 90 mm H x 18 mm W x 70 mm D Dimensions
Additional Description: SIEM-5SJ4145-7HG40 MCB 5SJ4 1P 240V 45A SAME PH 10K C-TRIP
Catalog Description: MCB UL489 1-P 45A C-TRIP SAME PHASE ONLY MINIATURE CIRCUIT-BREAKER 240 V 10 KA,1-POLE, C, 45 A, D=70 MM TO UL 489, SAME POLARITY
5SJ4145-7HG40 Application
Branch Circuit Protection Applications5SJ4145-7HG40 Item Features
- Can be used globally for all applications in residential, non-residential and industrial buildings, this facilitates the planning of installations and enhances export opportunities
- The devices can be used according to IEC/EN 60898-1 and UL 489, which means these devices can be installed anywhere in the world
- Can be used for both AC voltage and DC voltage up to 125 VAC
- Rated making and breaking capacity up to 14 kA in according with UL 489 and up to 15 kA in according with IEC 60947-2
- Fast mounting with busbars up to 115 A and feeder terminals up to 50 sq-mm
- Class C trip
5SJ4145-7HG40 Standards
UL 489, CSA 22.2 NO. 5-02, HACR, IEC/EN 60 898, IEC/EN 60 947-2SKU #2318274Part Number #5SJ4145-7HG40UNSPSC39121601UPC00754554932705
