Part Number # CLM0E02120
SKU # 2457695
CLM0E02120
Siemens CLM0E02120
Part Number # CLM0E02120
SKU # 2457695
Siemens CLM0E02120 Key Features
| Brand: | Siemens |
|---|---|
| Part Number # : | CLM0E02120 |
| SKU #: | 2457695 |
| Coil Power Rating: | 900 VA Pickup, 200 VA Holding |
| Coil Voltage: | 110/120 V AC |
| Contact Configuration: | 2NO |
| Dimensions: | 6.86 in H x 4.78 in W x 6.98 in D |
| Enclosure Type: | Open |
| Frequency Rating: | 50/60 Hz |
| Number of Auxiliary Contacts: | 4 |
| Number of Poles: | 2 |
| Operating Cycles: | 5000000 Cylces Contactor/Typical |
| Connection type: | Box Lug/Screw |
| Country of origin: | DO |
| Mounting type: | Surface |
| Manufacturer Name: | Siemens |
| UNSPSC: | 39121529 |
| UPC: | 00754554246840 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
Siemens CLM0E02120
Brand: Siemens
Part Number: CLM0E02120
Siemens Lighting Contactor, 110/120 VAC Coil, 100 A Maximum Load Current, 900 VA Pickup, 200 VA Holding Coil, 2 Pole, 50/60 Hz Frequency, Non-Combination Contact, 2NO Contact Configuration, 4 Auxiliary Contacts, Box Lug/Screw Connection, Open Enclosure, 5000000 Cycles Contactor/Typical Operating Cycles, Surface Mounting, 6.86 in H x 4.78 in W x 6.98 in D Dimensions
Additional Description: SIEM-CLM0E02120 CONTACTOR LTG M-HELD,100A,2NO,OPN,120V,
Catalog Description: Mechanically held lighting contactor, H2 0 N.C. / 2 N.O. poles, 110VAC 50HZ/120VAC 60HZ coil, Non-combination type, Enclosure NEMA type (open), No enclosure
CLM0E02120 Item Features
- Mechanically held operational mode
- Copper or aluminum material of the conductor for supply, load side outgoing feeder and copper conductor at magnet coil
- 75 deg C temperature of the conductor for load side outgoing feeder maximum permissible, conductor at magnet coil maximum permissible, conductor for supply maximum permissible
CLM0E02120 Standards
CSA Certified|UL ListedSKU #2457695Part Number #CLM0E02120UNSPSC39121529UPC00754554246840
Image provided may only be a representation of final product and may include optional equipment
