Part #:GB2CB08
SKU #: 36488
$277.32/6EA
Key Features
Part #:GB2CB08
SKU #: 36488
Brand: Square D
Actuator Type: Toggle
Amperage Rating: 3, 3 A
Dimensions: 0.59 in W x 2.64 in D x 2.91 in H
Enclosure Type: IP20
Frequency Rating: 50/60, 50/60 Hz
$277.32/6EA
- 1 ka at 48 VDC, 10 ka at 110 VAC, 1.5 ka at 24 VDC, 3 ka at 230/240 vac interrupt rating
Specifications
Brand: Square D
Actuator Type: Toggle
Amperage Rating: 3, 3 A
Dimensions: 0.59 in W x 2.64 in D x 2.91 in H
Enclosure Type: IP20
Frequency Rating: 50/60, 50/60 Hz
Interrupt Rating: 1/1.5/3/10, 1/1.5/3/10 kA, 1/10/1.5/3
Number of Poles: 1
Power Rating: 2, 2 W
Temperature Rating (Degrees F): -20 to 60, -20 to 60 deg C
Trip Range: 40, 40 A
Trip Type: Thermal Magnetic, Thermal/Magnetic
Voltage Rating: 250 to 277 VAC/48 VDC, 250/277 VAC, 48 VDC
Wire Size: 16 to 12, 16 to 12 AWG
Connection type: Terminal
Country of origin: FR
Mounting type: DIN Rail/Plate
Manufacturer Name: Schneider Electric
UNSPSC: 39121601
UPC: 00785901214625
Square D GB2CB08 Tesys Gb2 Motor Circuit Protector
Square D TeSys GB2 Motor Circuit Protector, 250/277 VAC, 48 VDC, 3 A, 2 W Power, 50/60 Hz Frequency, 1/1.5/3/10 kA Interrupt, Thermal/Magnetic Trip, 40 A Trip, 1 Pole, Toggle Actuator, Terminal Connection, 16 to 12 AWG Wire, IP20 Enclosure, DIN Rail/Plate Mounting, -20 to 60 deg C, 0.59 in W x 2.64 in D x 2.91 in H Dimensions
Additional Description: SQD -GB2CB08 CONTROL CIRCUIT BREAKER
Catalog Description: TeSys GB2 thermal magnetic circuit protector, 1 P, 3 A, Id = 40 A
Item FeaturesControl Circuit Applications
Item Features
Item FeaturesRoHS Compliant|UL 1077 File No. E164873 CCN QVNU2|CSA C22.2 No. 14 File No. LR25490 Class 2115 01|CE Certified|IEC 60947|NEMKO Certified|ECCN: EAR99|PROP65: Cancer and Reproductive harm - www.P65Warnings.ca.gov
