Part Number # B145
SKU # 2360396
Image Disclaimers Message
B145
Siemens B145 Molded Case Circuit Breaker
Part Number # B145
SKU # 2360396
$32.44 / Each
Typical price:$100.50 / Each
Siemens B145 Key Features
| Brand: | Siemens |
|---|---|
| Part Number # : | B145 |
| SKU #: | 2360396 |
| Actuator Type: | Toggle |
| Amperage Rating: | 45, 45 A |
| Dimensions: | 3 in L x 1 in W x 4 in H |
| Frequency Rating: | 60, 60 Hz |
| Interrupt Rating: | 10, 10 kA |
| Number of Poles: | 1 |
| Phase: | 1 |
| Temperature Rating (Degrees F): | 40, 40 deg C |
| Trip Type: | Thermal Magnetic, Thermal/Magnetic |
| Type: | Type BL |
| Wire Size: | 8 to 6 AWG, 8 to 4 AWG |
| Connection type: | Bolt-On |
| Country of origin: | MX |
| Mounting type: | Panel |
| Manufacturer Name: | Siemens |
| UNSPSC: | 39121601 |
| UPC: | 00783643263475 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
$32.44 / Each
Typical price:$100.50 / Each
Quantity:
- Siemens Molded Case Circuit Breaker, Type BL, 120 V AC, 45 A, 60 Hz Frequency, 10 kA Interrupt, Thermal Magnetic Trip, 1 Pole, 1 ph, Toggle Actuator, Bolt-On Connection, 8 to 6 AWG, 8 to 4 AWG Wire, Panel Mounting, 40 deg C, 3 in L x 1 in W x 4 in H Dimensions
B145 Application
Electrical Distribution ApplicationsB145 Item Features
- Sense when an over current occurs
- Measure the amount of over current
- Act by tripping quickly enough to prevent damage to itself and associated conductors
- Mounting with insta-wire
- 8 to 6 AWG copper, 8 to 4 AWG aluminum wire
B145 Standards
ULLISTED/CSA/NOMCERTIFIEDSKU #2360396Part Number #B145UNSPSC39121601UPC00783643263475
