Part Number # BQ1M030
SKU # 2170330
Image provided may only be a representation of
final product and may include optional equipment
BQ1M030
Siemens BQ1M030 Molded Case Circuit Breaker
Part Number # BQ1M030
SKU # 2170330
Siemens BQ1M030 Key Features
| Brand: | Siemens |
|---|---|
| Part Number # : | BQ1M030 |
| SKU #: | 2170330 |
| Amperage Rating: | 30, 30 A |
| Dimensions: | 4 in L x 1 in W x 3 in H |
| Frame: | BQ, BQ Series |
| Frequency Rating: | 60, 60 Hz |
| Interrupt Rating: | 10, 10 kA |
| Number of Poles: | 1 |
| Temperature Rating (Degrees F): | 40, 40 deg C |
| Trip Type: | Thermal Magnetic, Thermal/Magnetic |
| Wire Size: | 14 to 6 AWG Cu/12 to 10 AWG Al |
| Country of origin: | MX |
| Mounting type: | Bolt-On, Bolted-On |
| Manufacturer Name: | Siemens |
| UNSPSC: | 39121601 |
| UPC: | 00783643238060 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
Siemens BQ1M030 Molded Case Circuit Breaker
Brand: Siemens
Part Number: BQ1M030
Siemens Molded Case Circuit Breaker, 120 VAC, 30 A, 60 Hz Frequency, 10 kA Interrupt, BQ Frame, Thermal/Magnetic Trip, 1 Pole, 14 to 6 AWG Cu/12 to 10 AWG Al Wire, Bolted-On Mounting, 40 deg C, 4 in L x 1 in W x 3 in H Dimensions
Additional Description: SIEM-BQ1M030 (N) BREAKER 30A 1P 120V 10K 50C BQ MARINE NON-CANCELABLE, NON-RETURNABLE
Catalog Description: Siemens Low Voltage Molded Case Circuit Breakers General Purpose MCCBs - Type BQ, 1-Pole, 120VAC are Circuit Protection Molded Case Circuit Breakers. Type BQ Special Features MARINE Application Electrical Distribution Standard UL 489 Voltage Rating 120V Amperage Rating 30A Trip Range Thermal Magnetic Interrupt Rating 10 AIC Number Of Poles 1P
BQ1M030 Application
Electrical Distribution ApplicationsBQ1M030 Standards
UL 489SKU #2170330Part Number #BQ1M030UNSPSC39121601UPC00783643238060
