- Provide easy lug in/lug out connection
Specifications
Brand: Siemens
Amperage Rating: 80, 80 A
Dimensions: 3 in L x 3 in W x 4 in H
Frequency Rating: 60, 60 Hz
Interrupt Rating: 22, 22 kA
Number of Poles: 3
Phase: 3
Temperature Rating (Degrees F): 40, 40 deg C
Trip Type: Thermal Magnetic, Thermal/Magnetic
Type: Type BQ
Voltage Rating: 240, 240 VAC
Wire Size: 4 to 1/0 AWG, 2 to 1/0 AWG
Connection type: Bolt-On
Country of origin: MX
Mounting type: Bolt-On, Bolted-On
Manufacturer Name: Siemens
UNSPSC: 39121601
UPC: 00783643224841
Siemens BQ3B080H Molded Case Circuit Breaker
Siemens Molded Case Circuit Breaker, Type BQ, 240 VAC, 80 A, 60 Hz Frequency, 22 kA Interrupt, Thermal/Magnetic Trip, 3 Pole, 3 ph, Bolt-On Connection, 4 to 1/0 AWG, 2 to 1/0 AWG Wire, Bolted-On Mounting, 40 deg C, 3 in L x 3 in W x 4 in H Dimensions
Additional Description: SIEM-BQ3B080H (N) BRKR BQH 3P 240V 80A 22K NON-CANCELABLE, NON-RETURNABLE
Catalog Description: Siemens Low Voltage Molded Case Circuit Breakers General Purpose MCCBs are Circuit Protection Molded Case Circuit Breakers. 3-Pole Common-Trip circuit breaker type BQH. Rated 240V (080A) (AIR 22 kA). Special features Load side lugs are included.
Item FeaturesElectrical Distribution Applications
Item Features
Item FeaturesUL 489|HACR Rated
