Siemens ED42B100L Sentron Molded Case Circuit Breaker
Siemens ED42B100L Sentron Molded Case Circuit Breaker
Part #:ED42B100L
SKU #: 2234066
Key Features
Part #:ED42B100L
SKU #: 2234066
Brand: Siemens
Amperage Rating: 100, 100 A
Dimensions: 3 in L x 7 in W x 6 in H
Frame: ED, ED/125A
Frequency Rating: 50/60, 50/60 Hz
Interrupt Rating: 18, 18 kA
- All ED frame circuit breakers may be reverse connected
- 10 to 1/0 AWG copper aluminum wire
- Varying actuator
- Varying enclosure
- Blue label
Siemens ED42B100L Sentron Molded Case Circuit Breaker
Siemens Sentron Molded Case Circuit Breaker, Type ED4 Low Voltage, 480 VAC/250 VDC, 100 A, 50/60 Hz Frequency, 18 kA Interrupt, ED Frame, Thermal/Magnetic Trip, 2 Pole, 1 ph, Line/Load Lug Connection, 10 to 1/0 AWG Wire, Panel Mounting, 40 deg C, 3 in L x 7 in W x 6 in H Dimensions
Additional Description: SIEM-ED42B100L BRKR ED4 2P 480V 100A LUG
Catalog Description: SIEMENS LOW VOLTAGE SENTRON MOLDED CASE CIRCUIT BREAKER WITH THERMAL - MAGNETICTRIP UNIT. STANDARD 40 DEG C BREAKER ED FRAME WITH STANDARD BREAKING CAPACITY. 100A 2-POLE (18KAIC AT 480V). NON-INTERCHANGEABLE TRIP UNIT. SPECIAL FEATURES LINE AND LOAD SIDE LUGS (LN1E100) WIRE RANGE 10 - 1/0AWG (CU/AL). DIMENSIONS (W x H x D) IN 2.00 x 6.4 x 3.92.
