Siemens LGG2B015L Molded Case Circuit Breaker
Part Number # LGG2B015L
SKU # 2284587
$1156.50 / Each
Typical price:$3855.00 / Each
Siemens LGG2B015L Key Features
| Brand: | Siemens |
|---|---|
| Part Number # : | LGG2B015L |
| SKU #: | 2284587 |
| Amperage Rating: | 15, 15 A |
| Dimensions: | 5.4 in H x 2 in W x 2.8 in D |
| Frame: | LGG |
| Frequency Rating: | 50/60, 50/60 Hz |
| Interrupt Rating: | 65, 65 kA |
| Number of Poles: | 2 |
| Phase: | 1 |
| Temperature Rating (Degrees F): | 40, 40 deg C |
| Trip Type: | Thermal Magnetic, Thermal/Magnetic |
| Type: | Low Voltage |
| Wire Size: | 14 to 10 AWG Al/Cu |
| Connection type: | Cable In/Out/Line/Load Side Lug |
| Country of origin: | MX |
| Mounting type: | DIN Rail/Threaded |
| Manufacturer Name: | Siemens |
| UNSPSC: | 39121601 |
| UPC: | 00887621279004 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
$1156.50 / Each
Typical price:$3855.00 / Each
Quantity:
- Siemens Molded Case Circuit Breaker, Low Voltage, 480 V AC, 15 A, 50/60 Hz Frequency, 65 kA Interrupt, LGG Frame, Thermal Magnetic Trip, 2 Pole, 1 ph, Cable In/Out/Line/Load Side Lug Connection, 14 to 10 AWG Al/Cu Wire, DIN Rail/Threaded Mounting, 40 deg C, 5.4 in H x 2 in W x 2.8 in D Dimensions
LGG2B015L Application
General Purpose and Industrial ApplicationsLGG2B015L Item Features
- LGG frame with very high breaking capacity
LGG2B015L Standards
UL 489|CSA C22.2SKU #2284587Part Number #LGG2B015LUNSPSC39121601UPC00887621279004
