Part Number # MTG0050P
SKU # 2305845
Image Disclaimers Message
MTG0050P
Siemens MTG0050P Control Power Transformer
Part Number # MTG0050P
SKU # 2305845
$121.04 / Each
Typical price:$229.00 / Each
Siemens MTG0050P Key Features
| Brand: | Siemens |
|---|---|
| Part Number # : | MTG0050P |
| SKU #: | 2305845 |
| Dimensions: | 3.46 in H x 3 in W x 3.64 in D |
| Enclosure Type: | Open |
| Frequency Rating: | 50/60, 50/60 Hz |
| Insulation: | Class 130 deg C |
| Phase: | 1 |
| Primary Voltage: | 380, 380 V AC, 380 VAC |
| Secondary Voltage: | 24, 24 V AC, 24 VAC |
| Temperature Rating (Degrees F): | -4 to 104, -4 to 104 deg F |
| Type: | Class MTG |
| Connection type: | Screw Terminal, Terminal Screw |
| Country of origin: | MX |
| Mounting type: | Surface |
| Power factor: | 20, 20 %, 20% |
| Manufacturer Name: | Siemens |
| UNSPSC: | 39121026 |
| UPC: | 00754554312422 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
$121.04 / Each
Typical price:$229.00 / Each
Quantity:
- Siemens Control Power Transformer, Class MTG, 380 V AC Primary, 24 VAC Secondary, 50 VA Power, 50/60 Hz Frequency, 1 ph, Power Factor: 20 %, Screw Terminal Connection, Surface Mounting, Class 130 deg C Insulation, Open Enclosure, -4 to 104 deg F, 3.46 in H x 3 in W x 3.64 in D Dimensions
MTG0050P Application
Domestic and International ApplicationsMTG0050P Item Features
- Meets IP-20 specifications per IEC 529 for finger-safe protection when used with Siemens touch safe snap-on terminal cover kits
- Meets IP-00 specifications when covers are not used
- Insulation requirements is twice that of UL 5085
- Integrally molded terminals and barriers between terminals make breakage virtually impossible during wiring
- The MTG transformer construction is the same as our high quality class MT transformers
MTG0050P Standards
UL Listed|cUL Listed|ANSI Specified|CE Certified|CSA Certified|IEC/EN 61 558SKU #2305845Part Number #MTG0050PUNSPSC39121026UPC00754554312422
